Ball Bearings for Hinges
WHITE STAR COMPONENTS PRIVATE LIMITED are the Indian manufacturers, suppliers & exporters of all types of Stainless Steel Hinge Ball Bearings with various grades & finishes.
BALL BEARINGS FOR HINGES - SPACIFICATION CHART |
||
|---|---|---|
| Outer Dia (mm) | Inner Dia (mm) | Thickness (mm) |
| 11.00 | 5.80 | 4.90 |
| 11.70 | 5.75 | 5.50 |
| 11.70 | 7.00 | 5.50 |
| 12.20 | 7.00 | 5.20 |
| 12.20 | 7.00 | 5.50 |
| 12.60 | 7.00 | 5.50 |
| 13.50 | 7.00 | 5.50 |
| 13.50 | 7.00 | 5.80 |
| 14.00 | 8.00 | 5.50 |
| 14.00 | 7.70 | 5.20 |
| 14.20 | 8.00 | 5.20 |
| 14.30 | 8.00 | 4.80 |
| 14.30 | 8.00 | 5.50 |
| 14.30 | 8.00 | 5.80 |
| 14.60 | 8.00 | 6.50 |
